Shenzhou-14 (SZ-14)

Launch, orbit & landing data: Designation  52797 / 22060A Launch date - time  05 June 2022 - 02:44:10 UTC Launch site  Jiuquan, LA-4/SLS Launch vehicle  CZ-2F (#Y14) Shenzhou designation   nr Mass (kg)  8082 kg? Docking date - time  05 June2022 - 09:42 UTC Target spacecraft/port  Tiangong/Tianhe nadir Geocentric orbit :    - Perigee / Apogee  380 x 386 km    - Inclination  41.5°    - Period   min Undocking date - time  04 December 2022 - 03.01 UTC Time docked  181d, 17h, 19min Landing date - time  04 December 2022 - 12:09 UTC Landing location  41°39'13''N 100°03'11''E (Inner Mongolia, China) Flight Duration (d:hr:min)  182d, 9h, 25min Nbr orbits  2885 Landing crew  launch crew

Cai Xuzhe, Chen Dong and Liu Yang before launch.

Launched Crew

Note:

• Shenzhou 14 was the third spaceflight to the Tiangong space station, and the second with a planned duration of six months (180 days). Shenzhou 14 would also mark the beginning of Tiangong being permanently inhabited, with Shenzhou 14 departing after the arrival of Shenzhou 15, and the same being done on subsequent expeditions.
• Prior to launch, the Shenzhou 14 spacecraft was maintained in a state of near-readiness if needed as a lifeboat for the Shenzhou 13 crew.

Shenzhou-14 before integration.

China station in orbit.

Mission Report:

• The flight launched from Jiuquan Satellite Launch Center on 5 June 2022 at 02:44 UTC, following the launch of the Tianzhou 4 cargo resupply spacecraft. Just under 7 hours after launch, the spacecraft docked with the Tianhe core module's nadir docking port. The crew entered the station later the same day at 12:50 UTC.
• During the mission, the Shenzhou 15 spacecraft remained on standby to serve as an emergency rescue vehicle.
• The Shenzhou 14 crew carried out three spacewalks, worked on payloads both inside and outside the station, and carried out other scientific work during the six-month mission. The crew also oversaw the expansion of Tiangong with the addition of the Wentian and Mengtian laboratory cabin modules, which arrived at the station in July and October 2022 respectively. During Shenzhou 14's stay aboard Tiangong, the Tianzhou 5 cargo spacecraft arrived and docked with the station.
• Station expansion: On 24 July 2022, the Wentian module launched and successfully docked with the Tianhe's forward port. The crew of Shenzhou 14 opened the hatch and entered Wentian for the first time on 25 July 2022 at 02:03 UTC, to perform an inspection of the module. Wentian was later repositioned to Tianhe's starboard port, its final location.
• On 31 October 2022, the Mengtian module launched and successfully docked with Tianhe's forward port, and was repositioned to Tianhe's port-side port on 3 November 2022. Following Mengtian's reposition, the crew opened the hatch and entered Mengtian for the first time on 3 November 2022 at 07:12 UTC to inspect the module's interior.
• Spacewalks:On 1 September 2022, the first scheduled spacewalk of Shenzhou 15 was carried out by Chen Dong and Liu Yang, with Liu Yang becoming the second Chinese woman to carry out a spacewalk. The two exited the airlock of the Wentian lab module and completed a series of tasks, including installing an extended pump set on the exterior of the station, raising panoramic camera B, installing a workbench, and demonstrating procedures for an emergency return to the airlock. The spacewalk lasted for 6 hours and 7 minutes.
• On 17 September 2022, the second scheduled spacewalk was carried out by Chen Dong and Cai Xuzhe through the airlock of the Wentian lab module, with Liu Yang assisting the pair from inside the Tianhe core module. Chen and Cai completed the installation of foot restraints and extravehicular workbenches with support from the station's small robotic arm, performed further work on the extended pump set, and further verified EVA emergency rescue procedures. The spacewalk lasted for 4 hours and 12 minutes.
• On 17 November 2022, the third spacewalk was carried out by Chen Dong and Cai Xuzhe through the airlock of the Wentian lab module, with Liu Yang once again assisting the pair from inside the Tianhe core module. Chen and Cai installed an inter-chamber connection device between Tianhe and Mengtian, raised panoramic A on Wentian, and installed a small mechanical arm power-assisted handle. The spacewalk lasted for 5 hours and 34 minutes.

Shenzhou-14 recovery.

Crew back on Earth.

External links:

• Wikipedia: Descriptions
• Spacefacts: Satellite description

Astrophilately covers:

Launch cancel with MPO and "27" in cancel. Credit: #411

Launch cancel without MPO and "27". Credit: #411
